• The plastic trough body is made of polypropylene
• The grating is made of polished stainless steel AISI 304
• DN40 drain pipe diameter
• Odor trap height 40 mm

Adjustable legs:
They help to set the channel in the required position and height 68-85 mm.

Easy cleaning:
Removing the inlet from the siphon provides full access to the drain pipe and possible cleaning.

Channel dropping:
The bottom of the canal is dropped along its entire length, so that dirt can easily find its way into the waste.

Hydro isolation:
For ideal adhesion to the waterproofing, a connecting rim is created around the channel, and a waterproofing self-adhesive strip is included.

• Channel material: polypropylene
• Grate material: polished stainless steel
• Easy maintenance
• Grate width 64 mm
• Flow rate 48 l / min, drain 40 mm
• Span: 455 mm to 920 mm
