Installation method

• Installation in prefabricated walls, pre-wall installation in dry walls, universal installation into solid walls

Properties

• Supporting, blue powder coated WC element, square profile 30x30 mm with pre-assembled concealed cistern
• Frontal flushing, for dual flushing (3/6 L)
• Flush volume adjustable (large flush 4-7 L, small flush 2-3 L)
• Pre-assembled wall brackets and adjustable feet (0-200 mm)
• Water connection - top center
• Fully insulated against condensation

Special features

• Quiet Hydraulic Fill valve (Noise class 1 ISO 3822)
• Depth adjustable drain elbow (+/-20 mm)

Product contains

• Concealed cistern equipped with pre-installed stop valve – top center
• Water connection 1/2”
• PE drain elbow DN 90 mm with seal
• PE adapter DN 90 / 110 mm with seal
• Complete installation and fixing material

EN 14055
